Appendix B: Register Details
ICDIPR10 0x00001428 32 rw 0x00000000 Interrupt Priority Register_10
ICDIPR11
0x0000142C 32 rw 0x00000000 Interrupt Priority Register_11
ICDIPR12
0x00001430 32 rw 0x00000000 Interrupt Priority Register_12
ICDIPR13
0x00001434 32 rw 0x00000000 Interrupt Priority Register_13
ICDIPR14
0x00001438 32 rw 0x00000000 Interrupt Priority Register_14
ICDIPR15
0x0000143C 32 rw 0x00000000 Interrupt Priority Register_15
ICDIPR16
0x00001440 32 rw 0x00000000 Interrupt Priority Register_16
ICDIPR17
0x00001444 32 rw 0x00000000 Interrupt Priority Register_17
ICDIPR18
0x00001448 32 rw 0x00000000 Interrupt Priority Register_18
ICDIPR19
0x0000144C 32 rw 0x00000000 Interrupt Priority Register_19
ICDIPR20
0x00001450 32 rw 0x00000000 Interrupt Priority Register_20
ICDIPR21
0x00001454 32 rw 0x00000000 Interrupt Priority Register_21
ICDIPR22
0x00001458 32 rw 0x00000000 Interrupt Priority Register_22
ICDIPR23
0x0000145C 32 rw 0x00000000 Interrupt Priority Register_23
ICDIPTR0
0x00001800 32 ro 0x00000000 Interrupt Processor Targets
Register 0
ICDIPTR1
0x00001804 32 ro 0x00000000 Interrupt Processor Targets
Register 1
ICDIPTR2
0x00001808 32 ro 0x00000000 Interrupt Processor Targets
Register 2
ICDIPTR3
0x0000180C 32 ro 0x00000000 Interrupt Processor Targets
Register 3
ICDIPTR4
0x00001810 32 rw 0x00000000 Interrupt Processor Targets
Register 4
ICDIPTR5
0x00001814 32 ro 0x00000000 Interrupt Processor Targets
Register 5
ICDIPTR6
0x00001818 32 ro 0x00000000 Interrupt Processor Targets
Register 6
ICDIPTR7
0x0000181C 32 ro 0x00000000 Interrupt Processor Targets
Register 7
ICDIPTR8
0x00001820 32 rw 0x00000000 Interrupt Processor Targets
Register 8
ICDIPTR9
0x00001824 32 rw 0x00000000 Interrupt Processor Targets
Register 9
ICDIPTR10
0x00001828 32 rw 0x00000000 Interrupt Processor Targets
Register 10
ICDIPTR11
0x0000182C 32 rw 0x00000000 Interrupt Processor Targets
Register 11
Register Name Address Width Type Reset Value Description
