Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1438
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
ICDIPTR12 0x00001830 32 rw 0x00000000 Interrupt Processor Targets
Register 12
ICDIPTR13
0x00001834 32 rw 0x00000000 Interrupt Processor Targets
Register 13
ICDIPTR14
0x00001838 32 rw 0x00000000 Interrupt Processor Targets
Register 14
ICDIPTR15
0x0000183C 32 rw 0x00000000 Interrupt Processor Targets
Register 15
ICDIPTR16
0x00001840 32 rw 0x00000000 Interrupt Processor Targets
Register 16
ICDIPTR17
0x00001844 32 rw 0x00000000 Interrupt Processor Targets
Register 17
ICDIPTR18
0x00001848 32 rw 0x00000000 Interrupt Processor Targets
Register 18
ICDIPTR19
0x0000184C 32 rw 0x00000000 Interrupt Processor Targets
Register 19
ICDIPTR20
0x00001850 32 rw 0x00000000 Interrupt Processor Targets
Register 20
ICDIPTR21
0x00001854 32 rw 0x00000000 Interrupt Processor Targets
Register 21
ICDIPTR22
0x00001858 32 rw 0x00000000 Interrupt Processor Targets
Register 22
ICDIPTR23
0x0000185C 32 rw 0x00000000 Interrupt Processor Targets
Register 23
ICDICFR0
0x00001C00 32 ro 0x00000000 Interrupt Configuration
Register 0
ICDICFR1
0x00001C04 32 rw 0x00000000 Interrupt Configuration
Register 1
ICDICFR2
0x00001C08 32 rw 0x00000000 Interrupt Configuration
Register 2
ICDICFR3
0x00001C0C 32 rw 0x00000000 Interrupt Configuration
Register 3
ICDICFR4
0x00001C10 32 rw 0x00000000 Interrupt Configuration
Register 4
ICDICFR5
0x00001C14 32 rw 0x00000000 Interrupt Configuration
Register 5
ppi_status
0x00001D00 32 ro 0x00000000 PPI Status Register
spi_status_0
0x00001D04 32 ro 0x00000000 SPI Status Register 0
spi_status_1
0x00001D08 32 ro 0x00000000 SPI Status Register 1
ICDSGIR
0x00001F00 32 rw 0x00000000 Software Generated Interrupt
Register
Register Name Address Width Type Reset Value Description
