Appendix B: Register Details
Register (mpcore) SCU_CONTROL_REGISTER
Register SCU_CONTROL_REGISTER Details
ICPIDR4 0x00001FD0 32 rw 0x00000004 Peripheral ID4
ICPIDR5
0x00001FD4 32 rw 0x00000000 Peripheral ID5
ICPIDR6
0x00001FD8 32 rw 0x00000000 Peripheral ID6
ICPIDR7
0x00001FDC 32 rw 0x00000000 Peripheral ID7
ICPIDR0
0x00001FE0 32 rw 0x00000090 Peripheral ID0
ICPIDR1
0x00001FE4 32 rw 0x000000B3 Peripheral ID1
ICPIDR2
0x00001FE8 32 rw 0x0000001B Peripheral ID2
ICPIDR3
0x00001FEC 32 rw 0x00000000 Peripheral ID3
ICCIDR0
0x00001FF0 32 rw 0x0000000D Component ID0
ICCIDR1
0x00001FF4 32 rw 0x000000F0 Component ID1
ICCIDR2
0x00001FF8 32 rw 0x00000005 Component ID2
ICCIDR3
0x00001FFC 32 rw 0x000000B1 Component ID3
Name SCU_CONTROL_REGISTER
Relative Address 0x00000000
Absolute Address 0xF8F00000
Width 32 bits
Access Type rw
Reset Value 0x00000002
Description SCU Control Register
Register Name Address Width Type Reset Value Description
Field Name Bits Type Reset Value Description
reserved 31:7 rw 0x0 Reserved. Writes are ignored, read data is always
zero.
IC_standby_enable 6 rw 0x0 When set, this stops the Interrupt Controller clock
when no interrupts are pending, and no CPU is
performing a read/write request.
