Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1440
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (mpcore) SCU_CONFIGURATION_REGISTER
SCU_standby_enable 5 rw 0x0 When set, SCU CLK is turned off when all
processors are in WFI mode,
there is no pending request on the ACP (if
implemented), and there is no
remaining activity in the SCU.
When SCU CLK is off, ARREADYS, AWREADYS
and WREADYS on
the ACP are forced LOW. The clock is turned on
when any processor
leaves WFI mode, or if there is a new request on
the ACP.
Force_all_Device_to_p
ort0_enable
4 rw 0x0 When set, all requests from the ACP or processors
with AxCACHE =
NonCacheable Bufferable are forced to be issued
on the AXI Master port
M0.
SCU_Speculative_linefi
lls_enable
3 rw 0x0 When set, coherent linefill requests are sent
speculatively to the L2C-310
in parallel with the tag look-up. If the tag look-up
misses, the confirmed
linefill is sent to the L2C-310 and gets RDATA
earlier because the data
request was already initiated by the speculative
request. This feature works
only if the L2C-310 is present in the design.
SCU_RAMs_Parity_en
able
2 rw 0x0 1 = Parity on.
0 = Parity off. This is the default setting.
This bit is always zero if support for parity is not
implemented.
Address_filtering_enab
le
1 rw 0x1 1 = Addressing filtering on.
0 = Addressing filtering off.
The default value is the value of FILTEREN
sampled when nSCURESET
is deasserted.
This bit is always zero if the SCU is implemented
in the single master port
configuration.
SCU_enable 0 rw 0x0 1 = SCU enable.
0 = SCU disable. This is the default setting
Name SCU_CONFIGURATION_REGISTER
Field Name Bits Type Reset Value Description
