Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1449
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register ICCIAR Details
Register (mpcore) ICCEOIR
Register ICCEOIR Details
Register (mpcore) ICCRPR
Field Name Bits Type Reset Value Description
reserved 31:13 rw 0x0 reserved
CPUID 12:10 rw 0x0 Identifies the processor that requested the
interrupt.
Returns the number of the CPU interface that
made the request.
ACKINTID
(GIC_ACK_INTID)
9:0 rw 0x3FF The interrupt ID.
This read acts as an acknowledge for the
interrupt.
Name ICCEOIR
Software Name GIC_EOI
Relative Address 0x00000110
Absolute Address 0xF8F00110
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description End Of Interrupt Register
Field Name Bits Type Reset Value Description
reserved 31:13 rw 0x0 reserved
CPUID 12:10 rw 0x0 On completion of the processing of an SGI, this
field contains the CPUID value from the
corresponding ICCIAR access.
EOIINTID
(INTID)
9:0 rw 0x0 The ACKINTID value from the corresponding
ICCIAR access.
Name ICCRPR
Software Name GIC_RUN_PRIOR
Relative Address 0x00000114
Absolute Address 0xF8F00114
Width 32 bits
