Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1451
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register ICCABPR Details
Register (mpcore) ICCIDR
Register ICCIDR Details
Absolute Address 0xF8F0011C
Width 32 bits
Access Type rw
Reset Value 0x00000003
Description Aliased Non-secure Binary Point Register
Field Name Bits Type Reset Value Description
reserved 31:3 rw 0x0 reserved
Binary_point 2:0 rw 0x3 Provides an alias of the Non-secure ICCBPR.
Name ICCIDR
Relative Address 0x000001FC
Absolute Address 0xF8F001FC
Width 32 bits
Access Type ro
Reset Value 0x3901243B
Description CPU Interface Implementer Identification Register
Field Name Bits Type Reset Value Description
Part_number 31:20 ro 0x390 Identifies the peripheral
Architecture_version 19:16 ro 0x1 Identifies the architecture version
Revision_number 15:12 ro 0x2 Returns the revision number of the Interrupt
Controller. The implementer defines the
format of this field.
Implementer 11:0 ro 0x43B Returns the JEP106 code of the company that
implemented the Cortex-A9 processor
interface RTL. It uses the following construct:
[11:8] the JEP106 continuation code of the
implementer
[7] 0
[6:0] the JEP106 code [6:0] of the implementer
