Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1456
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register Auto_increment_Register Details
Register (mpcore) Private_Timer_Load_Register
Register Private_Timer_Load_Register Details
Access Type rw
Reset Value 0x00000000
Description Auto-increment Register
Field Name Bits Type Reset Value Description
31:0 rw 0x0 Auto-increment Register
This 32-bit register gives the increment value of
the Comparator Register when the
Auto-increment bit is set in the Timer Control
Register. Each Cortex-A9 processor
present has its own Auto-increment Register
If the comp enable and auto-increment bits are set
when the global counter reaches the
Comparator Register value, the comparator is
incremented by the auto-increment value,
so that a new event can be set periodically.
The global timer is not affected and goes on
incrementing
Name Private_Timer_Load_Register
Software Name TIMER_LOAD
Relative Address 0x00000600
Absolute Address 0xF8F00600
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description Private Timer Load Register
Field Name Bits Type Reset Value Description
31:0 rw 0x0 The Timer Load Register contains the value
copied to the Timer Counter Register when
it decrements down to zero with auto reload
mode enabled. Writing to the Timer Load
Register means that you also write to the Timer
Counter Register.
