Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1468
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (mpcore) ICDIIDR
Register ICDIIDR Details
Register (mpcore) ICDISR0
Note: This register is the first in an array of 3 identical registers listed in the table below. The details
provided in this section apply to the entire array.
Name ICDIIDR
Software Name GIC_DIST_IDENT
Relative Address 0x00001008
Absolute Address 0xF8F01008
Width 32 bits
Access Type ro
Reset Value 0x0102043B
Description Distributor Implementer Identification Register
Field Name Bits Type Reset Value Description
Implementation_Versio
n
31:24 ro 0x1 Gives implementation version number
Revision_Number
(GIC_REV)
23:12 ro 0x20 Return the revision number of the controller
Implementer
(GIC_IMPL)
11:0 ro 0x43B Implementer Number
Name ICDISR0
Software Name GIC_SECURITY0
Relative Address 0x00001080
Absolute Address 0xF8F01080
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description Interrupt Security Register_0
Name Address
ICDISR0 0xf8f01080
ICDISR1 0xf8f01084
ICDISR2 0xf8f01088
