Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1481
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register ICDIPTR5 Details
The ICDIPTR5 register always returns 0.
Register (mpcore) ICDIPTR6
Register ICDIPTR6 Details
The ICDIPTR6 register is used to indicate the target of interrupt ID#27.
Register (mpcore) ICDIPTR7
Register ICDIPTR7 Details
The ICDIPTR7 register is used to indicate the targets of interrupts ID#28-ID#31.
Field Name Bits Type Reset Value Description
reserved 31:0 ro 0x0 Reserved
Name ICDIPTR6
Software Name GIC_SPI_TARGET
Relative Address 0x00001818
Absolute Address 0xF8F01818
Width 32 bits
Access Type ro
Reset Value 0x00000000
Description Interrupt Processor Targets Register 6
Field Name Bits Type Reset Value Description
target_27
(GIC_SPI_CPUn)
25:24 ro 0x0 Targeted CPU(s) for interrupt ID#27
01: CPU 0 targeted
10: CPU 1 targeted
Name ICDIPTR7
Software Name GIC_SPI_TARGET
Relative Address 0x0000181C
Absolute Address 0xF8F0181C
Width 32 bits
Access Type ro
Reset Value 0x00000000
Description Interrupt Processor Targets Register 7
