Appendix B: Register Details
Register (mpcore) ICDIPTR16
Register ICDIPTR16 Details
The ICDIPTR16 register is used to target the interrupts ID#64-ID#67 to none, CPU 0, CPU 1, or both CPUs.
target_61
(GIC_SPI_CPUn)
9:8 rw 0x0 Targeted CPU(s) for interrupt ID#61
00: no CPU targeted
01: CPU 0 targeted
10: CPU 1 targeted
11: CPU 0 and CPU 1 are both targeted
target_60
(GIC_SPI_CPUn)
1:0 rw 0x0 Targeted CPU(s) for interrupt ID#60
00: no CPU targeted
01: CPU 0 targeted
10: CPU 1 targeted
11: CPU 0 and CPU 1 are both targeted
Name ICDIPTR16
Software Name GIC_SPI_TARGET
Relative Address 0x00001840
Absolute Address 0xF8F01840
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description Interrupt Processor Targets Register 16
Field Name Bits Type Reset Value Description
Field Name Bits Type Reset Value Description
target_67
(GIC_SPI_CPUn)
25:24 rw 0x0 Targeted CPU(s) for interrupt ID#67
00: no CPU targeted
01: CPU 0 targeted
10: CPU 1 targeted
11: CPU 0 and CPU 1 are both targeted
target_66
(GIC_SPI_CPUn)
17:16 rw 0x0 Targeted CPU(s) for interrupt ID#66
00: no CPU targeted
01: CPU 0 targeted
10: CPU 1 targeted
11: CPU 0 and CPU 1 are both targeted
