Appendix B: Register Details
Register (mpcore) ICDIPTR18
Register ICDIPTR18 Details
The ICDIPTR18 register is used to target the interrupts ID#72-ID#75 to none, CPU 0, CPU 1, or both CPUs.
target_69
(GIC_SPI_CPUn)
9:8 rw 0x0 Targeted CPU(s) for interrupt ID#69
00: no CPU targeted
01: CPU 0 targeted
10: CPU 1 targeted
11: CPU 0 and CPU 1 are both targeted
target_68
(GIC_SPI_CPUn)
1:0 rw 0x0 Targeted CPU(s) for interrupt ID#68
00: no CPU targeted
01: CPU 0 targeted
10: CPU 1 targeted
11: CPU 0 and CPU 1 are both targeted
Name ICDIPTR18
Software Name GIC_SPI_TARGET
Relative Address 0x00001848
Absolute Address 0xF8F01848
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description Interrupt Processor Targets Register 18
Field Name Bits Type Reset Value Description
Field Name Bits Type Reset Value Description
target_75
(GIC_SPI_CPUn)
25:24 rw 0x0 Targeted CPU(s) for interrupt ID#75
00: no CPU targeted
01: CPU 0 targeted
10: CPU 1 targeted
11: CPU 0 and CPU 1 are both targeted
target_74
(GIC_SPI_CPUn)
17:16 rw 0x0 Targeted CPU(s) for interrupt ID#74
00: no CPU targeted
01: CPU 0 targeted
10: CPU 1 targeted
11: CPU 0 and CPU 1 are both targeted
