Appendix B: Register Details
Register (mpcore) ICDIPTR19
Register ICDIPTR19 Details
The ICDIPTR19 register is used to target the interrupts ID#76-ID#79 to none, CPU 0, CPU 1, or both CPUs.
target_73
(GIC_SPI_CPUn)
9:8 rw 0x0 Targeted CPU(s) for interrupt ID#73
00: no CPU targeted
01: CPU 0 targeted
10: CPU 1 targeted
11: CPU 0 and CPU 1 are both targeted
target_72
(GIC_SPI_CPUn)
1:0 rw 0x0 Targeted CPU(s) for interrupt ID#72
00: no CPU targeted
01: CPU 0 targeted
10: CPU 1 targeted
11: CPU 0 and CPU 1 are both targeted
Name ICDIPTR19
Software Name GIC_SPI_TARGET
Relative Address 0x0000184C
Absolute Address 0xF8F0184C
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description Interrupt Processor Targets Register 19
Field Name Bits Type Reset Value Description
Field Name Bits Type Reset Value Description
target_79
(GIC_SPI_CPUn)
25:24 rw 0x0 Targeted CPU(s) for interrupt ID#79
00: no CPU targeted
01: CPU 0 targeted
10: CPU 1 targeted
11: CPU 0 and CPU 1 are both targeted
target_78
(GIC_SPI_CPUn)
17:16 rw 0x0 Targeted CPU(s) for interrupt ID#78
00: no CPU targeted
01: CPU 0 targeted
10: CPU 1 targeted
11: CPU 0 and CPU 1 are both targeted
