Appendix B: Register Details
Register (mpcore) ICDIPTR22
Register ICDIPTR22 Details
The ICDIPTR22 register is used to target the interrupts ID#88-ID#91 to none, CPU 0, CPU 1, or both CPUs.
target_85
(GIC_SPI_CPUn)
9:8 rw 0x0 Targeted CPU(s) for interrupt ID#85
00: no CPU targeted
01: CPU 0 targeted
10: CPU 1 targeted
11: CPU 0 and CPU 1 are both targeted
target_84
(GIC_SPI_CPUn)
1:0 rw 0x0 Targeted CPU(s) for interrupt ID#84
00: no CPU targeted
01: CPU 0 targeted
10: CPU 1 targeted
11: CPU 0 and CPU 1 are both targeted
Name ICDIPTR22
Software Name GIC_SPI_TARGET
Relative Address 0x00001858
Absolute Address 0xF8F01858
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description Interrupt Processor Targets Register 22
Field Name Bits Type Reset Value Description
Field Name Bits Type Reset Value Description
target_91
(GIC_SPI_CPUn)
25:24 rw 0x0 Targeted CPU(s) for interrupt ID#91
00: no CPU targeted
01: CPU 0 targeted
10: CPU 1 targeted
11: CPU 0 and CPU 1 are both targeted
target_90
(GIC_SPI_CPUn)
17:16 rw 0x0 Targeted CPU(s) for interrupt ID#90
00: no CPU targeted
01: CPU 0 targeted
10: CPU 1 targeted
11: CPU 0 and CPU 1 are both targeted
