Appendix B: Register Details
Register (mpcore) ICDICFR0
Register ICDICFR0 Details
The ICD ICFR 0 register controls the interrupt sensitivity of the 16 Software Generated Interrupts (SGI),
IRQ ID #0 to ID #15. This read-only register has two bits per interrupt that always indicate each SGI
interrupt is edge sensitive and must be handled by all of the targeted CPUs as indicated in the ICD IPTR
[3:0] registers.
target_93
(GIC_SPI_CPUn)
9:8 rw 0x0 Targeted CPU(s) for interrupt ID#93
00: no CPU targeted
01: CPU 0 targeted
10: CPU 1 targeted
11: CPU 0 and CPU 1 are both targeted
target_92
(GIC_SPI_CPUn)
1:0 rw 0x0 Targeted CPU(s) for interrupt ID#92
00: no CPU targeted
01: CPU 0 targeted
10: CPU 1 targeted
11: CPU 0 and CPU 1 are both targeted
Name ICDICFR0
Software Name GIC_INT_CFG
Relative Address 0x00001C00
Absolute Address 0xF8F01C00
Width 32 bits
Access Type ro
Reset Value 0x00000000
Description Interrupt Configuration Register 0
Field Name Bits Type Reset Value Description
Field Name Bits Type Reset Value Description
config_15
(MASK)
31:30 ro 0x0 Configuration for interrupt ID#15
10: edge sensitive and must be handeled by the
targeted CPU(s).
config_14
(MASK)
29:28 ro 0x0 Configuration for interrupt ID#14
10: edge sensitive and must be handeled by the
targeted CPU(s).
config_13
(MASK)
27:26 ro 0x0 Configuration for interrupt ID#13
10: edge sensitive and must be handeled by the
targeted CPU(s).
