Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1502
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (mpcore) ICDICFR3
config_40
(GIC_INT_CFG)
17:16 rw 0x0 Configuration for interrupt ID#40
01: high-level active
11: rising-edge
The lower bit is read-only and is always 1.
config_39
(GIC_INT_CFG)
15:14 rw 0x0 Configuration for interrupt ID#39
01: high-level active
11: rising-edge
The lower bit is read-only and is always 1.
config_38
(GIC_INT_CFG)
13:12 rw 0x0 Configuration for interrupt ID#38
01: high-level active
11: rising-edge
The lower bit is read-only and is always 1.
config_37
(GIC_INT_CFG)
11:10 rw 0x0 Configuration for interrupt ID#37
01: high-level active
11: rising-edge
The lower bit is read-only and is always 1.
config_36
(GIC_INT_CFG)
9:8 rw 0x0 Configuration for interrupt ID#36
01: high-level active
11: rising-edge
The lower bit is read-only and is always 1.
config_35
(GIC_INT_CFG)
7:6 rw 0x0 Configuration for interrupt ID#35
01: high-level active
11: rising-edge
The lower bit is read-only and is always 1.
config_34
(GIC_INT_CFG)
5:4 rw 0x0 Configuration for interrupt ID#34
01: high-level active
11: rising-edge
The lower bit is read-only and is always 1.
config_33
(GIC_INT_CFG)
3:2 rw 0x0 Configuration for interrupt ID#33
01: high-level active
11: rising-edge
The lower bit is read-only and is always 1.
config_32
(GIC_INT_CFG)
1:0 rw 0x0 Configuration for interrupt ID#32
01: high-level active
11: rising-edge
The lower bit is read-only and is always 1.
Name ICDICFR3
Field Name Bits Type Reset Value Description
