Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1504
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
config_57
(GIC_INT_CFG)
19:18 rw 0x0 Configuration for interrupt ID#57
01: high-level active
11: rising-edge
The lower bit is read-only and is always 1.
config_56
(GIC_INT_CFG)
17:16 rw 0x0 Configuration for interrupt ID#56
01: high-level active
11: rising-edge
The lower bit is read-only and is always 1.
config_55
(GIC_INT_CFG)
15:14 rw 0x0 Configuration for interrupt ID#55
01: high-level active
11: rising-edge
The lower bit is read-only and is always 1.
config_54
(GIC_INT_CFG)
13:12 rw 0x0 Configuration for interrupt ID#54
01: high-level active
11: rising-edge
The lower bit is read-only and is always 1.
config_53
(GIC_INT_CFG)
11:10 rw 0x0 Configuration for interrupt ID#53
01: high-level active
11: rising-edge
The lower bit is read-only and is always 1.
config_52
(GIC_INT_CFG)
9:8 rw 0x0 Configuration for interrupt ID#52
01: high-level active
11: rising-edge
The lower bit is read-only and is always 1.
config_51
(GIC_INT_CFG)
7:6 rw 0x0 Configuration for interrupt ID#51
01: high-level active
11: rising-edge
The lower bit is read-only and is always 1.
config_50
(GIC_INT_CFG)
5:4 rw 0x0 Configuration for interrupt ID#50
01: high-level active
11: rising-edge
The lower bit is read-only and is always 1.
config_49
(GIC_INT_CFG)
3:2 rw 0x0 Configuration for interrupt ID#49
01: high-level active
11: rising-edge
The lower bit is read-only and is always 1.
config_48
(GIC_INT_CFG)
1:0 rw 0x0 Configuration for interrupt ID#48
01: high-level active
11: rising-edge
The lower bit is read-only and is always 1.
Field Name Bits Type Reset Value Description
