Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1539
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
B.27 SD Controller (sdio)
Register Summary
Module Name SD Controller (sdio)
Base Address 0xE0100000 sd0
0xE0101000 sd1
Description SD2.0/ SDIO2.0/ MMC3.31 AHB Host ControllerRegisters
Vendor Info
Register Name Address Width Type Reset Value Description
SDMA_system_addres
s_register
0x00000000 32 rw 0x00000000 System DMA Address Register
Block_Size_Block_Cou
nt
0x00000004 32 mixed 0x00000000 Block size register
Block count register
Argument
0x00000008 32 rw 0x00000000 Argument register
Transfer_Mode_Comm
and
0x0000000C 32 mixed 0x00000000 Transfer mode register
Command register
Response0
0x00000010 32 ro 0x00000000 Response register
Response1
0x00000014 32 ro 0x00000000 Response register
Response2
0x00000018 32 ro 0x00000000 Response register
Response3
0x0000001C 32 ro 0x00000000 Response register
Buffer_Data_Port
0x00000020 32 rw 0x00000000 Buffer data port register
Present_State
0x00000024 25 ro 0x01F20000 Present State register
Host_control_Power_c
ontrol_Block_Gap_Con
trol_Wakeup_control
0x00000028 32 mixed 0x00000000 Host control register
Power control register
Block gap control register
Wake-up control register
Clock_Control_Timeou
t_control_Software_res
et
0x0000002C 27 mixed 0x00000000 Clock Control register
Timeout control register
Software reset register
Normal_interrupt_stat
us_Error_interrupt_stat
us
0x00000030 30 mixed 0x00000000 Normal interrupt status register
Error interrupt status register
Normal_interrupt_stat
us_enable_Error_interr
upt_status_enable
0x00000034 30 mixed 0x00000000 Normal interrupt status enable
register
Error interrupt status enable
register
