Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1572
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register Maximum_current_capabilities Details
Register (sdio)
Force_event_for_AutoCmd12_Error_Status_Force_event_register_for_error
_interrupt_sta tus
Register
Force_event_for_AutoCmd12_Error_Status_Force_event_register_for_error_interrupt_status
Details
The Force Event Register is not a physically implemented register. Rather, it is an address at which the
Auto CMD12 Error Status Register can be written.
Writing 1:set each bit of the Auto CMD12 Error Status Register
Writing 0:no effect.
The Force Event Register is not a physically implemented register. Rather, it is an address at which the
Error Interrupt Status register can be written. The effect of a write to this address will be reflected in the
Error Interrupt Status Register if the corresponding bit of the Error Interrupt Status Enable Register is set.
Writing 1:set each bit of the Error Interrupt Status Register
Writing 0:no effect
Description Maximum current capabilities register
Field Name Bits Type Reset Value Description
Maximum_Current_for
_1_8V
23:16 ro 0x0 Maximum Current for 1.8V
Maximum_Current_for
_3_0V
15:8 ro 0x0 Maximum Current for 3.0V
Maximum_Current_for
_3_3V
7:0 ro 0x1 Maximum Current for 3.3V
Name Force_event_for_AutoCmd12_Error_Status_Force_event_register_for_error_interru
pt_status
Relative Address 0x00000050
Absolute Address sd0: 0xE0100050
sd1: 0xE0101050
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description Force event register for Auto CMD12 error status register
Force event register for error interrupt status
