Appendix B: Register Details
Register (slcr) DDR_CLK_CTRL
Register DDR_CLK_CTRL Details
Note: the DDR_3x and DDR_2x clocks are asynchronous to each other and without a fixed frequency ratio.
The frequency of each DDR clock is independently programed. Generally, the DDR_3x clock runs faster
than the DDR2x clock.
CPU_1XCLKACT 27 rw 0x1 CPU_1x Clock control:
0: disable, 1: enable
CPU_2XCLKACT 26 rw 0x1 CPU_2x Clock control:
0: disable, 1: enable
CPU_3OR2XCLKACT 25 rw 0x1 CPU_3x2x Clock control:
0: disable, 1: enable
CPU_6OR4XCLKACT 24 rw 0x1 CPU_6x4x Clock control:
0: disable, 1: enable
reserved 23:14 rw 0x0 Reserved. Writes are ignored, read data is zero.
DIVISOR 13:8 rw 0x4 Frequency divisor for the CPU clock source.
(When PLL is being used, 1&3 are illegal values)
reserved 7:6 rw 0x0 Reserved. Writes are ignored, read data is zero.
SRCSEL 5:4 rw 0x0 Select the source used to generate the CPU clock:
0x: ARM PLL
10: DDR PLL
11: IO PLL
This field is reset by POR only.
reserved 3:0 rw 0x0 Reserved. Writes are ignored, read data is zero.
Name DDR_CLK_CTRL
Relative Address 0x00000124
Absolute Address 0xF8000124
Width 32 bits
Access Type rw
Reset Value 0x18400003
Description DDR Clock Control
Field Name Bits Type Reset Value Description
Field Name Bits Type Reset Value Description
DDR_2XCLK_DIVISO
R
31:26 rw 0x6 Frequency divisor for the ddr_2x clock
DDR_3XCLK_DIVISO
R
25:20 rw 0x4 Frequency divisor for the ddr_3x clock. (Only
even divisors are allowed)
