Chapter 6: Boot and Configuration
6.2 Device Start-up
This section includes the following subsections:
•section 6.2.1 Introduction
•section 6.2.2 Power Requirements
•section 6.2.3 Clocks and PLLs
•section 6.2.4 Reset Operations
•section 6.2.5 Boot Mode Pin Settings
•section 6.2.6 I/O Pin Connections for Boot Devices
6.2.1 Introduction
The Zynq-7000 device start-up requires proper voltage sequencing and I/O pin control. The flow of
the BootROM is controlled by the type of reset, the boot mode pin settings, and the Boot Image. The
BootROM expects certain pin connections for the selected boot device.
IMPORTANT: Zynq-7000 AP SoC devices have power, clock, and reset requirements that must be met
for successful BootROM execution. The data sheets and this section describe the requirements.
6.2.2 Power Requirements
The BootROM power requirements for the PS and PL are shown in Table 6-1. Power control is
discussed in Chapter 24, Power Management. Power supply voltage and ramp time requirements are
specified in the data sheet.
In the early stages of BootROM execution, the BootROM checks if the PL is powered up. If it is not
powered-up, the BootROM continues with execution. If the PL is powered up, the BootROM initiates
a cleaning cycle. The BootROM waits up to 90 seconds for the cleaning to occur. If the cleaning does
not finish in this amount of time, then a secure lockdown occurs.
If the PL is needed by the BootROM, it waits for up to 90 seconds for the PL to power-up. If the PL
does not power-up in this time frame, then the system shuts down without providing an error code.
Table 6-1: PS and PL Power Requirements
Boot Option
Secure After
POR Reset
PS Power PL Power
NAND, NOR, SD card, or Quad-SPI
Yes Required Required
No Required Not required
PL JTAG and EMIO JTAG Required Required
MIO JTAG Required Not required
