Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1635
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register WDT_CLK_SEL Details
Register (slcr) TZ_DMA_NS
Register TZ_DMA_NS Details
Register (slcr) TZ_DMA_IRQ_NS
Field Name Bits Type Reset Value Description
reserved 31:1 rw 0x0 Reserved. Writes are ignored, read data is zero.
SEL 0 rw 0x0 System watchdog timer clock source selection:
0: internal clock CPU_1x
1: external clock from PL via EMIO, or from
pinout via MIO
Name TZ_DMA_NS
Relative Address 0x00000440
Absolute Address 0xF8000440
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description DMAC TrustZone Config
Field Name Bits Type Reset Value Description
reserved 31:1 rw 0x0 Should Be Zero
DMAC_NS 0 rw 0x0 TZ security (connected to boot_manager_ns on
DMAC):
0: secure, DMAC operates in the secure state.
1: non-secure, DMAC operates in the non-secure
state.
Name TZ_DMA_IRQ_NS
Relative Address 0x00000444
Absolute Address 0xF8000444
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description DMAC TrustZone Config for Interrupts
