Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1636
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register TZ_DMA_IRQ_NS Details
Register (slcr) TZ_DMA_PERIPH_NS
Register TZ_DMA_PERIPH_NS Details
Register (slcr) PSS_IDCODE
Field Name Bits Type Reset Value Description
reserved 31:16 rw 0x0 Should Be Zero
DMA_IRQ_NS 15:0 rw 0x0 TZ security (connected to boot_irq_ns on DMAC):
0: secure, DMAC operates in the secure state.
1: non-secure, DMAC interrupt/event bit is in the
non-secure state.
Name TZ_DMA_PERIPH_NS
Relative Address 0x00000448
Absolute Address 0xF8000448
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description DMAC TrustZone Config for Peripherals
Field Name Bits Type Reset Value Description
reserved 31:4 rw 0x0 Should Be Zero
DMAC_PERIPH_NS 3:0 rw 0x0 TZ security (connected to boot_periph_ns on
DMAC):
0: secure, DMAC operates in the secure state.
1: non-secure, reset value: DMAC peripheral i/f is
in the non-secure state.
Name PSS_IDCODE
Relative Address 0x00000530
Absolute Address 0xF8000530
Width 32 bits
Access Type ro
Reset Value x
Description PS IDCODE
