Appendix B: Register Details
Register DDR_CMD_STA Details
Register (slcr) DDR_URGENT_SEL
Register DDR_URGENT_SEL Details
Field Name Bits Type Reset Value Description
reserved 31:1 rw 0x0 Reserved. Writes are ignored, read data is zero.
CMD_Q_NEMPTY 0 ro 0x0 DDR controller command store fill status.
0: indicates DDRC command store is empty.
1: indicates there are commands pending in
DDRC command store.
This register is a continuous monitor of the
ddrc_co_q_not_empty output from the DDR
controller, which is first synchronised from
ddr_clk into amba1x_clk.
Name DDR_URGENT_SEL
Relative Address 0x0000061C
Absolute Address 0xF800061C
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description DDR Urgent Select
Field Name Bits Type Reset Value Description
reserved 31:16 rw 0x0 Reserved. Writes are ignored, read data is zero.
S3_ARQOS_MODE 15:14 rw 0x0 Selects between the AXI port s3_awqos[3], fabric
signal or static register to drive the DDRC urgent
bit.
00: DDRC s3_awurgent bit is driven from the
'S3_AWURGENT' field of the
DDR_URGENT_VAL register.
01: DDRC s3_awurgent bit is driven from the
s3_awqos bit.
10: DDRC s3_awurgent bit is driven from the
fabric ddr_arb[3] input.
11: undefined
