Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1642
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
S2_ARQOS_MODE 13:12 rw 0x0 Selects between the AXI port s2_arqos[3], fabric
signal or static register to drive the DDRC urgent
bit.
00: DDRC s2_arurgent bit is driven from the
'S2_ARURGENT' field of the
DDR_URGENT_VAL register.
01: DDRC s2_arurgent bit is driven from the
s2_arqos bit.
10: DDRC s2_arurgent bit is driven from the fabric
ddr_arb[2] input.
11: undefined
S1_ARQOS_MODE 11:10 rw 0x0 Selects between the AXI port s1_arqos[3], fabric
signal or static register to drive the DDRC urgent
bit.
00: DDRC s1_arurgent bit is driven from the
'S1_ARURGENT' field of the
DDR_URGENT_VAL register.
01: DDRC s1_arurgent bit is driven from the
s1_arqos bit.
10: DDRC s1_arurgent bit is driven from the fabric
ddr_arb[1] input.
11: undefined.
S0_ARQOS_MODE 9:8 rw 0x0 Selects between the fabric signal or static register
to drive the DDRC urgent bit.
00: DDRC s0_arurgent bit is driven from the
'S0_ARURGENT' field of the
DDR_URGENT_VAL register.
x1: undefined
10: DDRC s0_arurgent bit is driven from the fabric
ddr_arb[0] input.
11: undefined
S3_AWQOS_MODE 7:6 rw 0x0 Selects between the AXI port s3_awqos[3], fabric
signal or static register to drive the DDRC urgent
bit.
00: DDRC s3_awurgent bit is driven from the
'S3_AWURGENT' field of the
DDR_URGENT_VAL register.
01: DDRC s3_awurgent bit is driven from the
s3_awqos bit.
10: DDRC s3_awurgent bit is driven from the
fabric ddr_arb[3] input.
11: undefined
Field Name Bits Type Reset Value Description
