Appendix B: Register Details
Register (slcr) MIO_PIN_10
Register MIO_PIN_10 Details
L2_SEL 4:3 rw 0x0 Level 2 Mux Select
00: Level 3 Mux
01: SRAM/NOR Data Bit 6, Input/Output
10: NAND Flash IO Bit 4, Input/Output
11: SDIO 1
Power Control, Output
L1_SEL 2 rw 0x0 Level 1 Mux Select
0: Level 2 Mux
1: Trace Port Data Bit 15, Output
L0_SEL 1 rw 0x0 Level 0 Mux Select
0: Level 1 Mux
1: Quad SPI 1 Flash Memory Clock, Output
TRI_ENABLE 0 rw 0x1 Operates the same as
MIO_PIN_00[TRI_ENABLE]
Name MIO_PIN_10
Relative Address 0x00000728
Absolute Address 0xF8000728
Width 32 bits
Access Type rw
Reset Value 0x00001601
Description MIO Pin 10 Control
Field Name Bits Type Reset Value Description
Field Name Bits Type Reset Value Description
reserved 31:14 rw 0x0 reserved
DisableRcvr 13 rw 0x0 Operates the same as MIO_PIN_00[DisableRcvr]
PULLUP 12 rw 0x1 Operates the same as MIO_PIN_00[PULLUP]
IO_Type 11:9 rw 0x3 Operates the same as MIO_PIN_00[IO_Type]
Speed 8 rw 0x0 Operates the same as MIO_PIN_00[Speed]
