Appendix B: Register Details
Register MIO_PIN_15 Details
Register (slcr) MIO_PIN_16
Reset Value 0x00001601
Description MIO Pin 15 Control
Field Name Bits Type Reset Value Description
reserved 31:14 rw 0x0 reserved
DisableRcvr 13 rw 0x0 Operates the same as MIO_PIN_00[DisableRcvr]
PULLUP 12 rw 0x1 Operates the same as MIO_PIN_00[PULLUP]
IO_Type 11:9 rw 0x3 Operates the same as MIO_PIN_00[IO_Type]
Speed 8 rw 0x0 Operates the same as MIO_PIN_00[Speed]
L3_SEL 7:5 rw 0x0 Level 3 Mux Select
000: GPIO 15 (bank 0), Input/Output
001: CAN 0 Tx, Output
010: I2C 0 Serial Data, Input/Output
011: SWDT Reset, Output
100: SDIO 1 IO Bit 3, Input/Output
101: SPI 1 Slave Select 2, Output
110: reserved
111: UART 0 TxD, Output
L2_SEL 4:3 rw 0x0 Level 2 Mux Select
00: Level 3 Mux
01: SRAM/NOR Address Bit 0, Output
10: reserved
11: SDIO 1 Power Control, Output
L1_SEL 2 rw 0x0 Level 1 Mux Select
0: Level 2 Mux
1: Trace Port Data Bit 1, Output
L0_SEL 1 rw 0x0 Level 0 Mux Select
0: Level 1 Mux
1= Not Used
TRI_ENABLE 0 rw 0x1 Operates the same as
MIO_PIN_00[TRI_ENABLE]
Name MIO_PIN_16
Relative Address 0x00000740
Absolute Address 0xF8000740
Width 32 bits
