Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1664
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register MIO_PIN_19 Details
Relative Address 0x0000074C
Absolute Address 0xF800074C
Width 32 bits
Access Type rw
Reset Value 0x00001601
Description MIO Pin 19 Control
Field Name Bits Type Reset Value Description
reserved 31:14 rw 0x0 reserved
DisableRcvr 13 rw 0x0 Operates the same as MIO_PIN_00[DisableRcvr]
PULLUP 12 rw 0x1 Operates the same as MIO_PIN_00[PULLUP]
IO_Type 11:9 rw 0x3 Operates the same as MIO_PIN_00[IO_Type]
Speed 8 rw 0x0 Operates the same as MIO_PIN_00[Speed]
L3_SEL 7:5 rw 0x0 Level 3 Mux Select
000: GPIO 19 (bank 0), Input/Output
001: CAN 0 Tx, Output
010: I2C 0 Serial Data, Input/Output
011: reserved
100: SDIO 0 IO Bit 1, Input/Output
101: SPI 0 Slave Select 1, Output
110: TTC 0 Clock, Input
111: UART 0 TxD, Output
L2_SEL 4:3 rw 0x0 Level 2 Mux Select
00: Level 3 Mux
01: SRAM/NOR Address Bit 4, Output
10: NAND Flash IO Bit 11, Input/Output
111: SDIO 1 Power Control, Output
L1_SEL 2 rw 0x0 Level 1 Mux Select
0: Level 2 Mux
1: Trace Port Data Bit 7, Output
L0_SEL 1 rw 0x0 Level 0 Mux Select
0: Level 1 Mux
1: Ethernet 0 RGMII TxD Bit 2, Output
TRI_ENABLE 0 rw 0x1 Operates the same as
MIO_PIN_00[TRI_ENABLE]
