Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1700
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (slcr) MIO_MST_TRI0
Register MIO_MST_TRI0 Details
Parallel access to the master tri-state enables for MIO pins
Name MIO_MST_TRI0
Relative Address 0x0000080C
Absolute Address 0xF800080C
Width 32 bits
Access Type rw
Reset Value 0xFFFFFFFF
Description MIO pin Tri-state Enables, 31:0
Field Name Bits Type Reset Value Description
PIN_31_TRI 31 rw 0x1 Master Tri-state Enable for pin 31, active high
PIN_30_TRI 30 rw 0x1 Master Tri-state Enable for pin 30, active high
PIN_29_TRI 29 rw 0x1 Master Tri-state Enable for pin 29, active high
PIN_28_TRI 28 rw 0x1 Master Tri-state Enable for pin 28, active high
PIN_27_TRI 27 rw 0x1 Master Tri-state Enable for pin 27, active high
PIN_26_TRI 26 rw 0x1 Master Tri-state Enable for pin 26, active high
PIN_25_TRI 25 rw 0x1 Master Tri-state Enable for pin 25, active high
PIN_24_TRI 24 rw 0x1 Master Tri-state Enable for pin 24, active high
PIN_23_TRI 23 rw 0x1 Master Tri-state Enable for pin 23, active high
PIN_22_TRI 22 rw 0x1 Master Tri-state Enable for pin 22, active high
PIN_21_TRI 21 rw 0x1 Master Tri-state Enable for pin 21, active high
PIN_20_TRI 20 rw 0x1 Master Tri-state Enable for pin 20, active high
PIN_19_TRI 19 rw 0x1 Master Tri-state Enable for pin 19, active high
PIN_18_TRI 18 rw 0x1 Master Tri-state Enable for pin 18, active high
PIN_17_TRI 17 rw 0x1 Master Tri-state Enable for pin 17, active high
PIN_16_TRI 16 rw 0x1 Master Tri-state Enable for pin 16, active high
PIN_15_TRI 15 rw 0x1 Master Tri-state Enable for pin 15, active high
PIN_14_TRI 14 rw 0x1 Master Tri-state Enable for pin 14, active high
PIN_13_TRI 13 rw 0x1 Master Tri-state Enable for pin 13, active high
PIN_12_TRI 12 rw 0x1 Master Tri-state Enable for pin 12, active high
PIN_11_TRI 11 rw 0x1 Master Tri-state Enable for pin 11, active high
PIN_10_TRI 10 rw 0x1 Master Tri-state Enable for pin 10, active high
PIN_09_TRI 9 rw 0x1 Master Tri-state Enable for pin 9, active high
