Appendix B: Register Details
Register (slcr) GPIOB_CFG_CMOS25
Register GPIOB_CFG_CMOS25 Details
The only allowed values for this register are 0x00000000 (reset value) and 0x0C301100 (normal operation)
Register (slcr) GPIOB_CFG_CMOS33
reserved 18:16 rw 0x0 Reserved. Do not modify.
reserved 15:12 rw 0x0 Reserved. Do not modify.
reserved 11:8 rw 0x0 Reserved. Do not modify.
reserved 7:4 rw 0x0 Reserved. Do not modify.
reserved 3:0 rw 0x0 Reserved. Do not modify.
Name GPIOB_CFG_CMOS25
Relative Address 0x00000B08
Absolute Address 0xF8000B08
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description MIO GPIOB CMOS 2.5V config
Field Name Bits Type Reset Value Description
Field Name Bits Type Reset Value Description
reserved 31:28 rw 0x0 Reserved. Writes are ignored, read data is zero.
reserved 27:25 rw 0x0 Reserved. Do not modify.
reserved 24:22 rw 0x0 Reserved. Do not modify.
reserved 21:19 rw 0x0 Reserved. Do not modify.
reserved 18:16 rw 0x0 Reserved. Do not modify.
reserved 15:12 rw 0x0 Reserved. Do not modify.
reserved 11:8 rw 0x0 Reserved. Do not modify.
reserved 7:4 rw 0x0 Reserved. Do not modify.
reserved 3:0 rw 0x0 Reserved. Do not modify.
Name GPIOB_CFG_CMOS33
Relative Address 0x00000B0C
Absolute Address 0xF8000B0C
Width 32 bits
