Appendix B: Register Details
Register DDRIOB_DRIVE_SLEW_DATA Details
Value of this register is computed by EDK after taking into account the Silicon Revision and DDR Standard
and can be found in the initialization TCL file or FSBL code. Values other than the one computed by EDK
are not supported
Register (slcr) DDRIOB_DRIVE_SLEW_DIFF
Register DDRIOB_DRIVE_SLEW_DIFF Details
Value of this register is computed by EDK after taking into account the Silicon Revision and DDR Standard
and can be found in the initialization TCL file or FSBL code. Values other than the one computed by EDK
are not supported
Access Type rw
Reset Value 0x00000000
Description Drive and Slew controls for DQ pins of the DDR Interface
Field Name Bits Type Reset Value Description
reserved 31:27 rw 0x0 Reserved. Do not modify.
reserved 26:24 rw 0x0 Reserved. Do not modify.
reserved 23:19 rw 0x0 Reserved. Do not modify.
reserved 18:14 rw 0x0 Reserved. Do not modify.
reserved 13:7 rw 0x0 Reserved. Do not modify.
reserved 6:0 rw 0x0 Reserved. Do not modify.
Name DDRIOB_DRIVE_SLEW_DIFF
Relative Address 0x00000B64
Absolute Address 0xF8000B64
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description Drive and Slew controls for DQS pins of the DDR Interface
Field Name Bits Type Reset Value Description
reserved 31:27 rw 0x0 Reserved. Do not modify.
reserved 26:24 rw 0x0 Reserved. Do not modify.
reserved 23:19 rw 0x0 Reserved. Do not modify.
reserved 18:14 rw 0x0 Reserved. Do not modify.
reserved 13:7 rw 0x0 Reserved. Do not modify.
reserved 6:0 rw 0x0 Reserved. Do not modify.
