Appendix B: Register Details
Register (slcr) DDRIOB_DCI_CTRL
Register DDRIOB_DCI_CTRL Details
reserved 12 rw 0x0 Reserved. Do not modify.
reserved 11:10 rw 0x0 Reserved. Do not modify.
REFIO_EN 9 rw 0x0 Enables VRP,VRN
0: VRP/VRN not used
1: VRP/VRN used as refio
reserved 8:7 rw 0x0 Reserved. Do not modify.
VREF_EXT_EN 6:5 rw 0x0 Enables External VREF input
x0: Disable External VREF for lower 16 bits
x1: Enable External VREF for lower 16 bits
0x: Disable External VREF for upper 16 bits
1x: Enable External VREF for upper 16 bits
VREF_SEL 4:1 rw 0x0 Specifies DDR IOB Vref generator output:
0001: VREF = 0.6V for LPDDR2 with 1.2V IO
0010: VREF = 0.675V for DDR3L with 1.35V IO
0100: VREF = 0.75V for DDR3 with 1.5V IO
1000: VREF = 0.90V for DDR2 with 1.8V IO
VREF_INT_EN 0 rw 0x0 Enables VREF internal generator
Name DDRIOB_DCI_CTRL
Relative Address 0x00000B70
Absolute Address 0xF8000B70
Width 32 bits
Access Type rw
Reset Value 0x00000020
Description DDR IOB DCI Config
Field Name Bits Type Reset Value Description
Field Name Bits Type Reset Value Description
reserved 31:28 rw 0x0 Reserved. Writes are ignored, read data is zero.
reserved 27 rw 0x0 Reserved. Do not modify.
reserved 26 rw 0x0 Reserved. Do not modify.
reserved 25 rw 0x0 Reserved. Do not modify.
reserved 24 rw 0x0 Reserved. Do not modify.
reserved 23 rw 0x0 Reserved. Do not modify.
