Appendix B: Register Details
Register DDRIOB_DCI_STATUS Details
Field Name Bits Type Reset Value Description
reserved 31:14 ro 0x0 Reserved. Writes are ignored, read data is zero.
DONE 13 rw 0x0 DCI done signal
reserved 12 rw 0x0 Reserved. Do not modify.
reserved 11 rw 0x0 Reserved. Do not modify.
reserved 10 ro 0x0 Reserved. Do not modify.
reserved 9 ro 0x0 Reserved. Do not modify.
reserved 8 ro 0x0 Reserved. Do not modify.
reserved 7 ro 0x0 Reserved. Do not modify.
reserved 6 ro 0x0 Reserved. Do not modify.
reserved 5 ro 0x0 Reserved. Do not modify.
reserved 4:3 ro 0x0 Reserved. Do not modify.
reserved 2 ro 0x0 Reserved. Do not modify.
reserved 1 ro 0x0 Reserved. Do not modify.
LOCK 0 ro 0x0 DCI Status input Read Only
