Appendix B: Register Details
Register (pl353) memc_status
Register memc_status Details
The read-only memc_status Register provides information on the configuration of the SMC and also the
current state of the SMC. You cannot read this register in the Reset state
ecc_memcfg_1 0x00000404 13 rw 0x00000043 ECC Memory Configuation
Register 1
ecc_memcommand1_1
0x00000408 25 rw 0x01300080 ECC Memory Command 1
Register 1
ecc_memcommand2_1
0x0000040C 25 rw 0x01E00585 ECC Memory Command 2
Register 1
ecc_addr0_1
0x00000410 32 ro 0x00000000 ECC Address 0 Register 1
ecc_addr1_1
0x00000414 24 ro 0x00000000 ECC Address 1 Register 1
ecc_value0_1
0x00000418 32 ro 0x00000000 ECC Value 0 Register 1
ecc_value1_1
0x0000041C 32 ro 0x00000000 ECC Value 1 Register 1
ecc_value2_1
0x00000420 32 ro 0x00000000 ECC Value 2 Register 1
ecc_value3_1
0x00000424 32 ro 0x00000000 ECC Value 3 Register 1
Name memc_status
Software Name MEMC_STATUS
Relative Address 0x00000000
Absolute Address 0xE000E000
Width 13 bits
Access Type ro
Reset Value 0x00000000
Description Operating and Interrupt Status
Register Name Address Width Type Reset Value Description
Field Name Bits Type Reset Value Description
raw_ecc_int1
(RAW_ECC_INT1)
12 ro 0x0 NAND Flash ECC interrupt raw status:
0: Not asserted
1: Asserted
reserved 11 ro 0x0 Reserved. Do not modify.
ecc_int1
(ECC_INT1)
10 ro 0x0 NAND Flash ECC interrupt status after
mask/enable:
0: Not asserted
1: Asserted
reserved 9 ro 0x0 Reserved. Do not modify.
