Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1729
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register memif_cfg Details
Provides information on the configuration of the memory interface. You cannot read this register in the
Reset state. The state of this register cannot be changed.
Register (pl353) memc_cfg_set
Description SMC configuration information
Field Name Bits Type Reset Value Description
exclusive_monitors
(EX_MONITORS)
17:16 ro 0x1 Return the number of exclusive access monitor
resources that are implemented in the SMC.
B00: 0 monitors
b01: 1 monitor
b10: 2 monitors
b11: 4 monitors
reserved 15 ro 0x0 Reserved
remap1
(REMAP1)
14 ro 0x0 Return the value of the remap_1 input.
memory_width1
(MEMORY_WIDTH1)
13:12 ro 0x1 The width of the NAND Flash interface can be 8
or 16 bits.
00: 8 Bit Interface
01: 16 Bit Interface
memory_chips1
(MEMORY_CHIPS1)
11:10 ro 0x0 The NAND Flash interface provides one chip
select.
memory_type1
(MEMORY_TYPE1)
9:8 ro 0x2 SMC controller 1 supports the NAND Flash
interface with hardware assisted ECC.
reserved 7 ro 0x0 Reserved
remap0
(REMAP0)
6 ro 0x0 Return the value of the remap_0 input
memory_width0
(MEMORY_WIDTH0)
5:4 ro 0x0 The width of the SRAM/NOR interface is 8 bits.
memory_chips0
(MEMORY_CHIPS0)
3:2 ro 0x1 The SRAM/NOR interface provides two chip
selects. Reads as {0,1}
memory_type0
(MEMORY_TYPE0)
1:0 ro 0x1 SMC controller 0 supports the SRAM/NOR
interface.
Name memc_cfg_set
Software Name MEMC_SET_CONFIG
Relative Address 0x00000008
Absolute Address 0xE000E008
