Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1730
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register memc_cfg_set Details
The write-only memc_cfg_set enables the SMC to be changed to low-power state, and interrupts enabled.
You cannot write to this register in the Reset state.
Register (pl353) memc_cfg_clr
Register memc_cfg_clr Details
The write-only memc_cfg_clr enables the SMC to be moved out of the low-power state, and the interrupts
disabled. You cannot write to this register in the Reset state.
Width 7 bits
Access Type wo
Reset Value x
Description Enable interrupts and lower power state
Field Name Bits Type Reset Value Description
ecc_int_enable1
(ECC_INT_ENABLE1)
6 wo x NAND Flash ECC interrupt enable:
0: No change
1: Enable
reserved 5 wo x Reserved. Do not modify.
reserved 4:3 wo x Reserved, write as zero.
low_power_req
(LOW_POWER_REQ)
2 wo x Put SMC into low-power mode when memory
interface goes idle:
0: No change
1: Enable low-power state
int_enable1
(INT_ENABLE1)
1 wo x NAND Flash interrupt enable:
0: No change
1: Enable
int_enable0
(INT_ENABLE0)
0 wo x SRAM/NOR interrupt enable:
0: No change
1: Enable
Name memc_cfg_clr
Software Name MEMC_CLR_CONFIG
Relative Address 0x0000000C
Absolute Address 0xE000E00C
Width 7 bits
Access Type wo
Reset Value x
Description Disable interrupts and exit from low-power state
