Appendix B: Register Details
Register user_config Details
The user_config
is write-only and controls the status of the user_config[7:0] signals. You can write to this register in all
operating states.
Register (pl353) ecc_status_1
Register ecc_status_1 Details
The ecc_status
is read-only and contains status information for the ECC. Although this is a read-only register, the bottom
five bits can be written to clear the corresponding interrupts.To clear the interrupt, you must write a 1 to
the appropriate bit.
Field Name Bits Type Reset Value Description
user_config
(MASK)
7:0 wo x This value sets the state of the user_config[7:0]
outputs.
Name ecc_status_1
Software Name IF1_ECC
Relative Address 0x00000400
Absolute Address 0xE000E400
Width 30 bits
Access Type ro
Reset Value 0x00000000
Description ECC Status and Clear Register 1
