Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1749
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register ecc_addr1_1 Details
The ecc_addr1 Register is read-only and contains the upper 24 bits of the ECC address.
Register (pl353) ecc_value0_1
Register ecc_value0_1 Details
The five ecc_value Registers are read-only and contain block information for the ECC. Note: Writing any
value to an ecc_value Register clears the ecc_int bit.
Relative Address 0x00000414
Absolute Address 0xE000E414
Width 24 bits
Access Type ro
Reset Value 0x00000000
Description ECC Address 1 Register 1
Field Name Bits Type Reset Value Description
ecc_addr 23:0 ro 0x0 Address bits 55 to 32
Name ecc_value0_1
Relative Address 0x00000418
Absolute Address 0xE000E418
Width 32 bits
Access Type ro
Reset Value 0x00000000
Description ECC Value 0 Register 1
Field Name Bits Type Reset Value Description
ecc_int
(ECC_VALUE_INT)
31 ro 0x0 Interrupt flag for this value
ecc_valid
(ECC_VALUE_VALID)
30 ro 0x0 Indicate if this value is valid
ecc_read
(ECC_VALUE_READ)
29 ro 0x0 Indicate if the ECC value has been read from
memory
ecc_fail
(ECC_VALUE_FAIL)
28 ro 0x0 Indicate if this value has failed
ecc_correct
(ECC_VALUE_CORRE
CT)
27 ro 0x0 Indicate if this block is correctable
