Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1750
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (pl353) ecc_value1_1
Register ecc_value1_1 Details
The five ecc_value Registers are read-only and contain block information for the ECC. Note: writing any
value to an ecc_value Register clears the ecc_int bit.
Register (pl353) ecc_value2_1
reserved 26:24 ro 0x0 Reserved, read undefined
ecc_value
(ECC_VALUE)
23:0 ro 0x0 ECC value of check result for block, depending on
ECC configuration
Name ecc_value1_1
Relative Address 0x0000041C
Absolute Address 0xE000E41C
Width 32 bits
Access Type ro
Reset Value 0x00000000
Description ECC Value 1 Register 1
Field Name Bits Type Reset Value Description
Field Name Bits Type Reset Value Description
ecc_int
(ECC_VALUE_INT)
31 ro 0x0 Interrupt flag for this value
ecc_valid
(ECC_VALUE_VALID)
30 ro 0x0 Indicate if this value is valid
ecc_read
(ECC_VALUE_READ)
29 ro 0x0 Indicate if the ECC value has been read from
memory
ecc_fail
(ECC_VALUE_FAIL)
28 ro 0x0 Indicate if this value has failed
ecc_correct
(ECC_VALUE_CORRE
CT)
27 ro 0x0 Indicate if this block is correctable
reserved 26:24 ro 0x0 Reserved, read undefined
ecc_value
(ECC_VALUE)
23:0 ro 0x0 ECC value of check result for block, depending on
ECC configuration
Name ecc_value2_1
Relative Address 0x00000420
