Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1764
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register RX_thres_reg0 Details
Register (SPI) Mod_id_reg0
Register Mod_id_reg0 Details
Field Name Bits Type Reset Value Description
Threshold_of_RX_FIF
O
31:0 rw 0x1 Defines the level at which the RX FIFO not empty
interrupt is generated
Name Mod_id_reg0
Relative Address 0x000000FC
Absolute Address spi0: 0xE00060FC
spi1: 0xE00070FC
Width 32 bits
Access Type ro
Reset Value 0x00090106
Description Module ID register
Field Name Bits Type Reset Value Description
reserved 31:25 ro 0x0 Reserved, read as zero, ignored on write.
module_ID 24:0 ro 0x90106 Module ID number
