Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1777
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (ttc) Interval_Counter_1
Register Interval_Counter_1 Details
Register (ttc) Interval_Counter_2
Register Interval_Counter_2 Details
Register (ttc) Interval_Counter_3
Name Interval_Counter_1
Software Name INTERVAL_VAL
Relative Address 0x00000024
Absolute Address ttc0: 0xF8001024
ttc1: 0xF8002024
Width 16 bits
Access Type rw
Reset Value 0x00000000
Description Interval value
Field Name Bits Type Reset Value Description
Interval
(COUNT_VALUE)
15:0 rw 0x0 If interval is enabled, this is the maximum value
that the counter will count up to or down from.
Name Interval_Counter_2
Relative Address 0x00000028
Absolute Address ttc0: 0xF8001028
ttc1: 0xF8002028
Width 16 bits
Access Type rw
Reset Value 0x00000000
Description Interval value
Field Name Bits Type Reset Value Description
Interval
(INTERVAL_VAL)
15:0 rw 0x0 If interval is enabled, this is the maximum value
that the counter will count up to or down from.
Name Interval_Counter_3
Relative Address 0x0000002C
