Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1785
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register Interrupt_Enable_1 Details
Register (ttc) Interrupt_Enable_2
Register Interrupt_Enable_2 Details
Register (ttc) Interrupt_Enable_3
Absolute Address ttc0: 0xF8001060
ttc1: 0xF8002060
Width 6 bits
Access Type rw
Reset Value 0x00000000
Description ANDed with corresponding Interrupt
Register
Field Name Bits Type Reset Value Description
IEN 5:0 rw 0x0 Enables for bits 05:00 in Interrupt Register:
corresponding bits must be set to enable the
interrupt.
Name Interrupt_Enable_2
Relative Address 0x00000064
Absolute Address ttc0: 0xF8001064
ttc1: 0xF8002064
Width 6 bits
Access Type rw
Reset Value 0x00000000
Description ANDed with corresponding Interrupt
Register
Field Name Bits Type Reset Value Description
IEN 5:0 rw 0x0 Enables for bits 05:00 in Interrupt Register:
corresponding bits must be set to enable the
interrupt.
Name Interrupt_Enable_3
Relative Address 0x00000068
Absolute Address ttc0: 0xF8001068
ttc1: 0xF8002068
