Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1803
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (UART) Modem_sts_reg0
Register Modem_sts_reg0 Details
The Modem Status register indicates the current state of the control lines from the modem, or peripheral
device, to the CPU. In addition, four bits of the modem status register provide change of state or delta
Field Name Bits Type Reset Value Description
reserved 31:6 ro 0x0 Reserved, read as zero, ignored on write.
FCM 5 rw 0x0 Automatic flow control mode:
0: disable
Transmission is continuous regardless of the
value of the EMIOUARTxCTSN input, and the
EMIOUARTxRTSN output is driven completely
under software control.
1: enable
Transmission will only occur when the
EMIOUARTxCTSN input is asserted low, and the
EMIOUARTxRTSN output is driven using a
compare of the RX FIFO fill level to the
programmed FDEL value.
reserved 4:2 ro 0x0 Reserved, read as zero, ignored on write.
RTS 1 rw 0x0 Request to send output control:
This bit is ignored if automatic flow control mode
is enabled by FCM being high. If FCM is low, the
value of this bit is inverted when applied to the
EMIOUARTxRTSN output.
0: EMIOUARTxRTSN output forced to logic 1
1: EMIOUARTxRTSN output forced to logic 0
DTR 0 rw 0x0 Data Terminal Ready:
The value of this bit is inverted when applied to
the EMIOUARTxDTRN output.
0: EMIOUARTxDTRN output forced to logic 1
1: EMIOUARTxDTRN output forced to logic 0
Name Modem_sts_reg0
Software Name MODEMSR
Relative Address 0x00000028
Absolute Address uart0: 0xE0000028
uart1: 0xE0001028
Width 32 bits
Access Type mixed
Reset Value x
Description Modem Status Register
