Appendix B: Register Details
Register (UART) TX_RX_FIFO0
Register TX_RX_FIFO0 Details
Register (UART) Baud_rate_divider_reg0
REMPTY
(RXEMPTY)
1 ro 0x0 Receiver FIFO Full continuous status:
0: Rx FIFO is not empty
1: Rx FIFO is empty
RTRIG
(RXOVR)
0 ro 0x0 Receiver FIFO Trigger continuous status:
0: Rx FIFO fill level is less than RTRIG
1: Rx FIFO fill level is greater than or equal to
RTRIG
Name TX_RX_FIFO0
Software Name FIFO
Relative Address 0x00000030
Absolute Address uart0: 0xE0000030
uart1: 0xE0001030
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description Transmit and Receive FIFO
Field Name Bits Type Reset Value Description
Field Name Bits Type Reset Value Description
reserved 31:8 ro 0x0 Reserved, read as zero, ignored on write.
FIFO 7:0 rw 0x0 Operates as Tx FIFO and Rx FIFO.
Name Baud_rate_divider_reg0
Relative Address 0x00000034
Absolute Address uart0: 0xE0000034
uart1: 0xE0001034
Width 32 bits
Access Type mixed
Reset Value 0x0000000F
Description Baud Rate Divider Register
