Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1812
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (usb) ID
Register ID Details
IP supplier controller identification (revision and synthesized configuration). Hardwired (constant value).
Register (usb) HWGENERAL
ENDPTCTRL6 0x000001D8 24 mixed 0x00000000 Endpoints 1 to 11 (Device mode)
ENDPTCTRL7
0x000001DC 24 mixed 0x00000000 Endpoints 1 to 11 (Device mode)
ENDPTCTRL8
0x000001E0 24 mixed 0x00000000 Endpoints 1 to 11 (Device mode)
ENDPTCTRL9
0x000001E4 24 mixed 0x00000000 Endpoints 1 to 11 (Device mode)
ENDPTCTRL10
0x000001E8 24 mixed 0x00000000 Endpoints 1 to 11 (Device mode)
ENDPTCTRL11
0x000001EC 24 mixed 0x00000000 Endpoints 1 to 11 (Device mode)
Name ID
Relative Address 0x00000000
Absolute Address usb0: 0xE0002000
usb1: 0xE0003000
Width 32 bits
Access Type ro
Reset Value 0xE441FA05
Description IP version and revision, read-only
Register Name Address Width Type Reset Value Description
Field Name Bits Type Reset Value Description
CIVERSION 31:29 ro 0x7 Reserved, reads 111.
VERSION 28:25 ro 0x2 IP entire version code:
[VERSION].[REVISION][TAG] refers to IP
version 2.20a.
REVISION 24:21 ro 0x2 Refer to [VERSION].
TAG 20:16 ro 0x1 Refer to [VERSION].
reserved 15:14 ro 0x3 reserved, writes ignored.
NID 13:8 ro 0x3A Controller ID: Ones complement of [ID].
reserved 7:6 ro 0x0 reserved, writes ignored.
ID 5:0 ro 0x5 Controller ID: USB controller supports HS,
On-the-Go, and FS/LS.
Name HWGENERAL
