Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1814
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register HWHOST Details
Register (usb) HWDEVICE
Register HWDEVICE Details
Register (usb) HWTXBUF
Description Host Mode IP config constants, read-only
Field Name Bits Type Reset Value Description
TTPER 31:24 ro 0x10 VUSB_HS_TT_PERIODIC_CONTEXTS constant.
0x010: Sixteen periodic contexts in TT.
TTASY 23:16 ro 0x2 VUSB_HS_TT_ASYNC_CONTEXTS constant.
0x02: Two asynchronous contexts in TT.
15:4 ro 0x0 reserved
NPORT 3:1 ro 0x0 VUSB_HS_NUM_PORT constant.
000: one downstream port supported.
HC 0 ro 0x1 VUSB_HS_HOST constant.
1: Host mode supported.
Name HWDEVICE
Relative Address 0x0000000C
Absolute Address usb0: 0xE000200C
usb1: 0xE000300C
Width 6 bits
Access Type ro
Reset Value 0x00000019
Description Device Mode IP config constants, read-only
Field Name Bits Type Reset Value Description
DEVEP 5:1 ro 0xC VUSB_HS_DEV_EP constant.
0x0C: Twelve endpoints supported (EP 0 to 11).
DC 0 ro 0x1 Controller supports Device Mode.
Name HWTXBUF
Relative Address 0x00000010
Absolute Address usb0: 0xE0002010
usb1: 0xE0003010
Width 32 bits
