Appendix B: Register Details
Register HWTXBUF Details
Register (usb) HWRXBUF
Register HWRXBUF Details
Access Type ro
Reset Value 0x80060A10
Description TxBuffer IP config constants, read-only
Field Name Bits Type Reset Value Description
reserved 31 ro 0x1 reserved
reserved 30:24 ro 0x0 reserved
TXCHANADD 23:16 ro 0x6 VUSB_HS_TX_CHAN_ADD constant.
0x06: Six address bits for each 64-byte endpoint
TxBuffer (VBUS_HS_TX_CHAN = 64).
TXADD 15:8 ro 0xA VUSB_HS_TX_ADD constant.
0x0A0: 10-bit address. TxBuffer size is 768.
TXBURST 7:0 ro 0x10 VUSB_HS_TX_BURST constant.
0x010: 16-byte bursts on AHB by DMA engine.
Name HWRXBUF
Relative Address 0x00000014
Absolute Address usb0: 0xE0002014
usb1: 0xE0003014
Width 32 bits
Access Type ro
Reset Value 0x00000A10
Description IP constants, RX buffer constants, read-only
Field Name Bits Type Reset Value Description
31:24 ro 0x0 reserved
RXADD 15:8 ro 0xA VUSB_HS_RX_ADD constant.
0x0A0: 10-bit address. RxBuffer address size is
1024.
RXBURST 7:0 ro 0x10 VUSB_HS_RX_BURST constant.
0x010: 16-byte bursts on AHB by DMA engine.
