Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1818
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register GPTIMER1CTRL Details
Register (usb) SBUSCFG
Register SBUSCFG Details
Register (usb) CAPLENGTH_HCIVERSION
Absolute Address usb0: 0xE000208C
usb1: 0xE000308C
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description GP Timer 1 Control
Field Name Bits Type Reset Value Description
GPTRUN 31 rw 0x0 Refer to GPTIMER0CTRL [GPTRUN].
GPTRST 30 wo 0x0 Refer to GPTIMER0CTRL [GPTRST].
29:25 ro 0x0 reserved
GPTMODE 24 rw 0x0 Refer to GPTIMER0CTRL [GPTMODE].
GPTCNT 23:0 rw 0x0 Refer to GPTIMER0CTRL [GPTCNT].
Name SBUSCFG
Relative Address 0x00000090
Absolute Address usb0: 0xE0002090
usb1: 0xE0003090
Width 3 bits
Access Type rw
Reset Value 0x00000003
Description DMA Master AHB Burst Mode
Field Name Bits Type Reset Value Description
AHBBRST 2:0 rw 0x3 VUSB_HS_AHBBRST constant.
Name CAPLENGTH_HCIVERSION
Relative Address 0x00000100
Absolute Address usb0: 0xE0002100
usb1: 0xE0003100
Width 32 bits
