Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1821
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (usb) DCIVERSION
Register DCIVERSION Details
Register (usb) DCCPARAMS
Register DCCPARAMS Details
Host and device mode capability.
PFL 1 ro 0x1 Programmable Frame List sizes (Host mode).
Software can specify the size of the frame list for
the periodic schedule. Configure the size using
the usb.USBCMD [FS2] [FS0] Frame List Size
field: 8, 16, 32, .... 512, 1024.
ADC 0 ro 0x0 0: 32-bit system memory address.
Name DCIVERSION
Relative Address 0x00000120
Absolute Address usb0: 0xE0002120
usb1: 0xE0003120
Width 16 bits
Access Type ro
Reset Value 0x00000001
Description Device Mode CI version constant
Field Name Bits Type Reset Value Description
Field Name Bits Type Reset Value Description
DCIVERSION 15:0 ro 0x1 VUSB_HS_DCIVERSION constant.
Name DCCPARAMS
Relative Address 0x00000124
Absolute Address usb0: 0xE0002124
usb1: 0xE0003124
Width 9 bits
Access Type ro
Reset Value 0x0000018C
Description EHCI, device and endpoint capabilities
