Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1822
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (usb) USBCMD
Register USBCMD Details
The serial bus host/device controller executes the command indicated in this register
Field Name Bits Type Reset Value Description
HC 8 ro 0x1 1: the controller supports EHCI compatible mode.
DC 7 ro 0x1 1: the controller supports Device mode.
6:5 ro 0x0 reserved
DEN 4:0 ro 0xC Number of endpoints supported in Device mode.
1100: 12 endpoints; control EP0 plus EP {11:1}.
Name USBCMD
Software Name CMD
Relative Address 0x00000140
Absolute Address usb0: 0xE0002140
usb1: 0xE0003140
Width 24 bits
Access Type mixed
Reset Value 0x00080000
Description USB Commands (EHCI extended)
Field Name Bits Type Reset Value Description
ITC 23:16 rw 0x8 Interrupt Threshold Control (EHCI) (Host and
mode). Program the maximum rate at which the
host controller will issue an interrupt.
0x00: Immediate
0x01: 1 micro-frame.
0x02: 2 micro-frames.
0x04: 4 micro-frames.
0x08: 8 micro-frames. (1 ms)
0x10: 16 micro-frames.
0x20: 32 micro-frames.
0x40: 64 micro-frames.
others: reserved.
FS2 15 rw 0x0 MSB bit of Frame List Size. Refer to [FS0] bit field
for description.
ATDTW 14 rw 0x0 Add dTD TripWire (Host extended).
This bit is used as a semaphore to ensure the
proper addition of a new dTD to an active
(primed) endpoint's linked list.
