Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1824
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (usb) USBSTS
Register USBSTS Details
Various USB bus and port interrupts, controller state status, controller event and general purpose timer
interrupts.
FS0
(FS01)
3:2 rw 0x0 Frame List Size (EHCI extended).
usb.USBCMD [15] [3] [2] bits:
000: 1024 elements (4096 bytes)
001: 512 elements (2048 bytes)
...
111: 8 elements (32 bytes)
RST 1 rw 0x0 Controller Reset and Status (ECHI) (Host and
Device mode).
RS 0 rw 0x0 Run/Stop (ECHI) (Host and Device modes).
Device Mode:
0: the controller halts activity after the current
packet transfer is complete.
1: the controller proceeds to execute the periodic
and async schedules.
Host Mode:
0: TBD
1: TBD
Name USBSTS
Software Name ISR
Relative Address 0x00000144
Absolute Address usb0: 0xE0002144
usb1: 0xE0003144
Width 26 bits
Access Type mixed
Reset Value 0x00000000
Description Interrupt/Raw Status (EHCI extended) (Host/Device)
Field Name Bits Type Reset Value Description
